本文讲述基于STM32G070进行ADC多通道采集，并分别介绍非DMA方式和DMA方式。
* |/ l% T, i' P  Z1. 非DMA方式采集
/ c. i6 {9 x  C  e( XADC初始化代码如下（使用STM32CubeMx自动生成），配置了3个通道：
* w4 y8 x: g4 T7 i
0 L, d9 K/ T- _$ y1 O

1. static void MX_ADC1_Init(void)

2. {
   4 n7 M: d1 F1 y3 M
3.
   , K& b9 }1 C7 |4 }/ ^
4.   /* USER CODE BEGIN ADC1_Init 0 */
   9 V" L& z& W$ r2 k2 T- q! _
5.
   , `4 \5 c2 t2 u/ e' m6 u% O' e4 M/ v
6.   /* USER CODE END ADC1_Init 0 */

7.
   / P8 L4 y3 P  G7 X5 N; y- i
8.   ADC_ChannelConfTypeDef sConfig = {0};
   ! u! ]4 P# R0 Q# ?, L9 G
9.
   / h  F3 n0 {. G' C7 Y8 ?# O
10.   /* USER CODE BEGIN ADC1_Init 1 */
    0 y; O5 P8 J) g5 n6 n* z
11.
    ; o" w/ M; `. D
12.   /* USER CODE END ADC1_Init 1 */
    , y* \3 _+ ^* f3 {
13.   /** Configure the global features of the ADC (Clock, Resolution, Data Alignment and number of conversion)
    - |+ [5 Q* y9 S3 e7 x
14.   */

15.   hadc1.Instance = ADC1;
    7 {  C0 C) p+ [) @5 J, T' c0 x$ C
16.   hadc1.Init.ClockPrescaler = ADC_CLOCK_SYNC_PCLK_DIV2;

17.   hadc1.Init.Resolution = ADC_RESOLUTION_12B;

18.   hadc1.Init.DataAlign = ADC_DATAALIGN_RIGHT;

19.   hadc1.Init.ScanConvMode = ADC_SCAN_ENABLE;

20.   hadc1.Init.EOCSelection = ADC_EOC_SINGLE_CONV;

21.   hadc1.Init.LowPowerAutoWait = DISABLE;

22.   hadc1.Init.LowPowerAutoPowerOff = DISABLE;
      e( g; `! O2 c
23.   hadc1.Init.ContinuousConvMode = DISABLE;
    . Y4 Y; ~9 m' {" G
24.   hadc1.Init.NbrOfConversion = 3;

25.   hadc1.Init.DiscontinuousConvMode = ENABLE;

26.   hadc1.Init.ExternalTrigConv = ADC_SOFTWARE_START;

27.   hadc1.Init.ExternalTrigConvEdge = ADC_EXTERNALTRIGCONVEDGE_NONE;
    - \/ P* V# N* U: \/ I% \
28.   hadc1.Init.DMAContinuousRequests = DISABLE;
    $ Q0 u! w. O$ S2 \6 S
29.   hadc1.Init.Overrun = ADC_OVR_DATA_PRESERVED;

30.   hadc1.Init.SamplingTimeCommon1 = ADC_SAMPLETIME_1CYCLE_5;
    " x& G9 i, z9 \6 F! a1 u' g# H) N; `/ a
31.   hadc1.Init.SamplingTimeCommon2 = ADC_SAMPLETIME_1CYCLE_5;
    # V3 u' e, Z0 P0 Y
32.   hadc1.Init.OversamplingMode = DISABLE;

33.   hadc1.Init.TriggerFrequencyMode = ADC_TRIGGER_FREQ_HIGH;
    $ p6 e9 W" D" x: M& j5 _
34.   if (HAL_ADC_Init(&hadc1) != HAL_OK)
    ; |7 c; l* Y1 l/ {  [% Q
35.   {
    3 x7 w. X  v0 Z
36.     Error_Handler();

37.   }

38.   /** Configure Regular Channel
    ; Q- E* `5 S  V5 ]9 o
39.   */

40.   sConfig.Channel = ADC_CHANNEL_4;
    ! \+ |, s6 ?% u3 r! z6 i
41.   sConfig.Rank = ADC_REGULAR_RANK_1;

42.   sConfig.SamplingTime = ADC_SAMPLINGTIME_COMMON_1;

43.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)
    / c; y% @% Z! p7 m0 I
44.   {
    5 U% m0 s* K& \
45.     Error_Handler();

46.   }
    % F+ ^9 \) b- W- H6 A7 O/ Y
47.   /** Configure Regular Channel
      L# r  z' h) s
48.   */
    2 |; C4 u% L) J! Q5 ^
49.   sConfig.Channel = ADC_CHANNEL_5;
    * @2 A  u8 f* h  P3 B- c# ~
50.   sConfig.Rank = ADC_REGULAR_RANK_2;
    0 ?  j; O5 X5 b
51.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)

52.   {

53.     Error_Handler();

54.   }

55.   /** Configure Regular Channel
    # ^% X3 f% x, ]( \& G2 A& l" I
56.   */
    3 [3 c  Q# d! L: g
57.   sConfig.Channel = ADC_CHANNEL_9;

58.   sConfig.Rank = ADC_REGULAR_RANK_3;
    0 |" E$ a2 ~; w% c( u  C  g
59.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)

60.   {

61.     Error_Handler();
    + g2 x6 A) M! ]. j) r: v
62.   }
    & C+ P$ x2 V, H/ T
63.   /* USER CODE BEGIN ADC1_Init 2 */
    ' x' {1 d5 E+ n3 y! @7 S+ {$ H
64.

65.   /* USER CODE END ADC1_Init 2 */

66.
    + B  ?2 q! P  j  ^$ Y5 d; L  i
67. }


复制代码

获取ADC数据
8 W) J* v8 J$ L9 A$ R# D

1. // 校准
   , A! I3 Q8 _6 Q+ o& h; B) B1 M
2. HAL_ADCEx_Calibration_Start(&hadc1);

3.
   + @, V9 |" B8 {7 N% M& X. F
4. for (idx = 0; idx < 3; idx++)
   , |3 ^7 W$ t9 y- Z0 Z
5. {

6.     HAL_ADC_Start(&hadc1);

7.     HAL_ADC_PollForConversion(&hadc1, 50);
   $ u- Y! k$ J7 h! \/ j: g, w
8.
   * r4 j, s2 I7 O# G" w3 f6 ]- X
9.     /* Check if the continous conversion is finished */
   . Y, ]/ F# M7 J% H1 S
10.     if(HAL_IS_BIT_SET(HAL_ADC_GetState(&hadc1), HAL_ADC_STATE_REG_EOC))

11.     {

12.         /* Get the converted value */

13.         AD_Value[idx] = HAL_ADC_GetValue(&hadc1);

14.     }
    $ v. B( H( }& e' |( P3 K. ?
15. }
    9 R0 _4 Q+ h& d7 S7 B% R- }* ]
16.
      {3 N% c5 f  f5 P+ Q
17. HAL_ADC_Stop(&hadc1);
    6 I! X% H( z/ U0 L1 c

复制代码

1.1 关于ADC扫描定序（scan sequencer）
* f7 M- I8 k& P8 W% n: Q8 W/ fADC scan sequencer can be used in two different modes. 配置ADC多通道采集时，对于各个通道的采集顺序有两种方式：

! Z. q# n9 x# h2 }
( ^9 N4 X3 t( s1 B4 OSequencer fully configurable (The order in which the channels are scanned is independent from the channel number)
# w: o' a2 H) y0 v采用这种方式时，ADC的通道扫描顺序将和channel number不再相关，如1中代码，就采用了这种方式
7 W- s9 v5 S, }0 p1 X; j

1. //扫描方式：ADC_SCAN_ENABLE
   8 h, b* x% j' E- w1 T0 a
2. hadc1.Init.ScanConvMode = ADC_SCAN_ENABLE;

3. //...
     w& ^" V0 |" A* R0 q$ O7 f9 n
4. sConfig.Channel = ADC_CHANNEL_5;
   * W( [0 G0 S: B4 |( @
5. sConfig.Rank = ADC_REGULAR_RANK_2;

6. if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)

7. {

8.     Error_Handler();
   ; C& Q4 }8 I/ }: o( ?% l) D: X
9. }

10.

11. sConfig.Channel = ADC_CHANNEL_6;
    , P: |" h, B5 f' k2 X
12. sConfig.Rank = ADC_REGULAR_RANK_1;
    # V+ E* j+ ]! u, Y6 N
13. if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)

14. {
    ) `4 y2 Y& o$ J# n- O" j: A; t
15.     Error_Handler();

16. }


复制代码

如果按照如上代码配置，在采集时，将先采集channel 6，再采集channel 5。但是使用该方式时，需要注意Only channel 0 to channel 14 can be selected in this sequence。即channel 15/16/17/18无法使用该方式，如果需要使用channel 15-18，则可以使用下面第二种扫描方式。
7 u8 ^; v5 b: o  y1 Z3 F1 K

Sequencer not fully configurable (The order in which the channels are scanned is defined by the channel number)
这种方式比较好理解，就是按照channel number的大小，按顺序进行扫描，配置代码如下：
" X& s2 G! F8 }- |  p

1. // 扫描方式：ADC_SCAN_SEQ_FIXED

2. hadc1.Init.ScanConvMode = ADC_SCAN_SEQ_FIXED;
   $ t  w, k7 ?5 w* t3 j+ w
3.

4. sConfig.Channel = ADC_CHANNEL_16;

5. sConfig.Rank = ADC_RANK_CHANNEL_NUMBER;
   9 C6 y& @! U* G$ J9 h( L  f
6. if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)
   ' S# x/ Z0 A9 k4 z. E" {" {. D
7. {

8.     Error_Handler();
   2 Q" n' x3 l' ^( b. `2 l& G
9. }
   $ K) b" E3 }; q  w) x3 L% a

复制代码

2. DMA方式采集
直接上代码：
  I0 x' F; l; Q3 N9 L

1. static void MX_ADC1_Init(void)

2. {

3.

4.   /* USER CODE BEGIN ADC1_Init 0 */
   ; Y' S; l) W" D* B, @9 A
5.

6.   /* USER CODE END ADC1_Init 0 */
   " z7 N5 F7 p0 J, m7 w$ C
7.

8.   ADC_ChannelConfTypeDef sConfig = {0};
   / r( `6 l, \9 j/ {  N9 V
9.
   ! }, w4 M5 f5 t8 P5 d$ }$ L# F  ~
10.   /* USER CODE BEGIN ADC1_Init 1 */

11.
    5 @1 m2 i2 ^! m! k+ y7 P3 y* |
12.   /* USER CODE END ADC1_Init 1 */

13.   /** Configure the global features of the ADC (Clock, Resolution, Data Alignment and number of conversion)
    ( n# }" v" D: P0 F) n4 H& p1 a- U
14.   */

15.   hadc1.Instance = ADC1;
    # Y0 `2 \+ `, E0 n
16.   hadc1.Init.ClockPrescaler = ADC_CLOCK_ASYNC_DIV1;
    - s) y7 S. {4 W$ i/ E2 i6 G
17.   hadc1.Init.Resolution = ADC_RESOLUTION_12B;
    ( ?' I- q  d4 [5 j1 G
18.   hadc1.Init.DataAlign = ADC_DATAALIGN_RIGHT;
    ! D  t! S9 m$ ?6 w8 [1 O! [% a
19.   hadc1.Init.ScanConvMode = ADC_SCAN_SEQ_FIXED;
    ; J! P; m8 _; h! R
20.   hadc1.Init.EOCSelection = ADC_EOC_SINGLE_CONV;

21.   hadc1.Init.LowPowerAutoWait = DISABLE;
    ! {. d  Y& J0 l2 Y6 S, G( v, o" K
22.   hadc1.Init.LowPowerAutoPowerOff = DISABLE;
    4 G5 m! ^# b; K( n/ e
23.   hadc1.Init.ContinuousConvMode = ENABLE;

24.   hadc1.Init.DiscontinuousConvMode = DISABLE;
    ( Z+ y' ~. D- I
25.   hadc1.Init.ExternalTrigConv = ADC_SOFTWARE_START;

26.   hadc1.Init.ExternalTrigConvEdge = ADC_EXTERNALTRIGCONVEDGE_NONE;
    9 |5 ^# ]% i  [6 P! M* i9 I
27.   hadc1.Init.DMAContinuousRequests = ENABLE;

28.   hadc1.Init.Overrun = ADC_OVR_DATA_OVERWRITTEN;
    - c) ?8 @6 z4 z0 W- ~
29.   hadc1.Init.SamplingTimeCommon1 = ADC_SAMPLETIME_12CYCLES_5;
    1 d" p" G, p1 k6 W6 Y3 E
30.   hadc1.Init.OversamplingMode = DISABLE;
    , k: [; u6 P& B3 l) {
31.   hadc1.Init.TriggerFrequencyMode = ADC_TRIGGER_FREQ_HIGH;
    4 q; r( e8 R* ^& M0 ?1 J# q
32.   if (HAL_ADC_Init(&hadc1) != HAL_OK)
    7 \9 j: s. v' y! [0 K
33.   {
    4 u* p# f% ~' |1 ^  ^% Q
34.     Error_Handler();
    3 H) T  s/ e9 k/ ^
35.   }

36.   /** Configure Regular Channel

37.   */
    + N4 ^+ `$ T% E; A9 E  J9 V6 F+ h$ U
38.   sConfig.Channel = ADC_CHANNEL_4;
    6 A: r9 H( U9 x+ d- o2 X5 e
39.   sConfig.Rank = ADC_RANK_CHANNEL_NUMBER;
      z' D. Y# k) f
40.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)
    ) p$ v0 m% \" n" P( U2 [
41.   {

42.     Error_Handler();
    , w% }; [+ J( ^& w4 z4 P7 n7 M- Y% u
43.   }

44.   /** Configure Regular Channel

45.   */
    1 ]) `) `- J) }# K! f8 s
46.   sConfig.Channel = ADC_CHANNEL_5;

47.   sConfig.Rank = ADC_RANK_CHANNEL_NUMBER;
    ' `4 u9 l; _) @
48.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)

49.   {
    5 w8 X# ~2 o& ~! I# }
50.     Error_Handler();

51.   }

52.   /** Configure Regular Channel
    ( Y; N/ E- Y/ \4 L% P5 z! _7 i
53.   */
    ) K9 h- L+ ^/ _4 R+ C
54.   sConfig.Channel = ADC_CHANNEL_9;
    1 w2 L' A1 w$ j& @* b
55.   sConfig.Rank = ADC_RANK_CHANNEL_NUMBER;
      `$ S1 Y5 ^" ^' ?
56.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)
    3 [  P& M/ H# r1 t
57.   {

58.     Error_Handler();

59.   }

60.   /** Configure Regular Channel
    $ O# j9 o4 w/ v
61.   */
    1 e: z5 A0 m8 i
62.   sConfig.Channel = ADC_CHANNEL_10;
    / l8 w! x8 @* w# w/ \% ~
63.   sConfig.Rank = ADC_RANK_CHANNEL_NUMBER;
    2 |" a$ P8 F. R: @, W: h+ S6 b& G
64.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)
    5 w7 _3 j+ g! h
65.   {
    * M% X" {- g( w. N' R$ j
66.     Error_Handler();
    9 b. m. J: M; |. C
67.   }
    5 e) L/ R- {( y( n' b" W, m+ Z  o, E4 q8 o
68.   /** Configure Regular Channel

69.   */

70.   sConfig.Channel = ADC_CHANNEL_16;
    7 U1 B# r2 O0 u
71.   sConfig.Rank = ADC_RANK_CHANNEL_NUMBER;
    ; L& J) o; J7 k4 F
72.   if (HAL_ADC_ConfigChannel(&hadc1, &sConfig) != HAL_OK)
    7 ~( @5 b6 |" }1 ]; B, k
73.   {
    : E- l# m) `4 k  h- ^7 U- p3 n
74.     Error_Handler();

75.   }
    * O' l( A( l) H! [. c
76.   /* USER CODE BEGIN ADC1_Init 2 */

77.
    * {( g- I( I) P- E
78.   /* USER CODE END ADC1_Init 2 */

79.

80. }
    ; E% v# k+ s. y1 a4 O, F# n5 z
81.

82. static void MX_DMA_Init(void)

83. {
    / L: ]$ C0 p1 X5 A7 U2 B( H" R7 q
84.

85.   /* DMA controller clock enable */

86.   __HAL_RCC_DMA1_CLK_ENABLE();
    9 i! u% \1 y: g/ Q7 P
87.

88.   /* DMA interrupt init */

89.   /* DMA1_Channel1_IRQn interrupt configuration */

90.   HAL_NVIC_SetPriority(DMA1_Channel1_IRQn, 0, 0);
    ; s) c0 A% ^  p3 Q  ]) |" |
91.   HAL_NVIC_EnableIRQ(DMA1_Channel1_IRQn);
    6 T0 W. L6 W& f7 i
92.

93. }
    ( E, r4 o8 }( x8 n: j  r  _" J
94.

95. void HAL_ADC_MspInit(ADC_HandleTypeDef* hadc)
    % J: {. y! K0 u! P0 ?
96. {

97.   GPIO_InitTypeDef GPIO_InitStruct = {0};
    - x. q  J- ?- y! M
98.   if(hadc->Instance==ADC1)

99.   {

100.   /* USER CODE BEGIN ADC1_MspInit 0 */

101.

102.   /* USER CODE END ADC1_MspInit 0 */

103.     /* Peripheral clock enable */
     $ z# {7 z& ^* J* G6 a; ^5 w
104.     __HAL_RCC_ADC_CLK_ENABLE();
     # m4 c* `3 ]' N0 v
105.

106.     __HAL_RCC_GPIOA_CLK_ENABLE();
     6 v& s) N6 M9 `! U, }
107.     __HAL_RCC_GPIOB_CLK_ENABLE();
     9 K& {# G$ @+ \3 {* _" o0 _
108.     /**ADC1 GPIO Configuration

109.     PA4     ------> ADC1_IN4

110.     PA5     ------> ADC1_IN5
     ( S8 F& J3 L, R) S) T' f4 M5 x" k  \
111.     PB1     ------> ADC1_IN9

112.     PB2     ------> ADC1_IN10
     ( s8 V( z' E+ V& I3 I. m
113.     PB12     ------> ADC1_IN16
     , _. _$ ~) M: c0 \$ e: \
114.     */
     5 D8 j6 b" z3 J2 x
115.     GPIO_InitStruct.Pin = GPIO_PIN_4|GPIO_PIN_5;
     5 i+ g3 f$ G' i; D( U9 |
116.     GPIO_InitStruct.Mode = GPIO_MODE_ANALOG;
     , @& b9 \; S0 T% ?
117.     GPIO_InitStruct.Pull = GPIO_NOPULL;
     ' r: `0 ]2 y1 n& L! h+ v, m
118.     HAL_GPIO_Init(GPIOA, &GPIO_InitStruct);

119.

120.     GPIO_InitStruct.Pin = GPIO_PIN_1|GPIO_PIN_2|GPIO_PIN_12;
     : X0 `1 F& q! }8 d" r- q( V* W# {
121.     GPIO_InitStruct.Mode = GPIO_MODE_ANALOG;
     4 E$ }  c4 {# C4 O; T1 M
122.     GPIO_InitStruct.Pull = GPIO_NOPULL;

123.     HAL_GPIO_Init(GPIOB, &GPIO_InitStruct);

124.

125.     /* ADC1 DMA Init */

126.     /* ADC1 Init */
     - o& D& g' d. p$ U! t3 [0 p
127.     hdma_adc1.Instance = DMA1_Channel1;

128.     hdma_adc1.Init.Request = DMA_REQUEST_ADC1;

129.     hdma_adc1.Init.Direction = DMA_PERIPH_TO_MEMORY;
     * L( J) c- B9 Z3 P; e3 J
130.     hdma_adc1.Init.PeriphInc = DMA_PINC_DISABLE;

131.     hdma_adc1.Init.MemInc = DMA_MINC_ENABLE;

132.     hdma_adc1.Init.PeriphDataAlignment = DMA_PDATAALIGN_WORD;
     5 O: W/ f8 v6 _
133.     hdma_adc1.Init.MemDataAlignment = DMA_MDATAALIGN_WORD;

134.     hdma_adc1.Init.Mode = DMA_CIRCULAR;

135.     hdma_adc1.Init.Priority = DMA_PRIORITY_LOW;

136.     if (HAL_DMA_Init(&hdma_adc1) != HAL_OK)

137.     {
     , C' B' L; e8 I! V
138.       Error_Handler();
     ' P9 G0 o" h  u+ t
139.     }
     / d) i& U5 l5 ]$ s- H
140.
     # R) J& j& H% }, Y. H% N
141.     __HAL_LINKDMA(hadc,DMA_Handle,hdma_adc1);

142.
     - d! }4 H4 h; K
143.   /* USER CODE BEGIN ADC1_MspInit 1 */
     ! `2 i9 ~, V" D1 Z* ~
144.

145.   /* USER CODE END ADC1_MspInit 1 */

146.   }

147.
     , \5 ?( n' p5 Y
148. }


复制代码

初始化完成后，即可使用：

1. //开始ADC转换

2. HAL_ADCEx_Calibration_Start(&hadc1);

3. HAL_ADC_Start_DMA(&hadc1, (uint32_t *)&AD_Value_Buffer, AD_DMA_BUFF_LENGTH);

复制代码

注：AD_Value_Buffer为事先定义好的数组，长度为AD_DMA_BUFF_LENGTH
接下来，无需CPU参与，DMA将会把ADC采集到数据搬运至AD_Value_Buffer的地址中，当长度达到AD_DMA_BUFF_LENGTH时，将从头开始，此时会覆盖数据。

# C% r' J7 r4 c

: k+ }! `5 d  c" m+ \' m1 a4 j
9 ]  y* d% O6 |1 |
! R: k9 E  |, Q, A
& n, B2 v% v" X. `
3 M5 O+ g% L. K0 u! S
